Product Details:
Payment & Shipping Terms:
|
| Color: | Black | Material: | Plastic |
|---|---|---|---|
| Engine: | 6HK1 | ||
| High Light: | ZAX330 Hitachi Electric Parts,ZAX330 Hitachi External Line |
||
0004777 External Line ZAX330
Recommendations for inspection and maintenance
1. Cut off the power To repair or replace electrical components, you must disconnect the wires and connectors. First, remove the negative terminal of the battery. If you forget it, it will cause damage to the wire harness, fuse and fuse, and even cause a fire due to a short circuit.
2. Color code of wire harness
| Code | Color | Code | Color |
| R | red | W | white |
| L | blue | G | green |
| Or | orange | Lg | light green |
| Y | yellow | B | black |
| Br | brown | P | pink |
| Gr | gray | V | purple |
3. Precautions for connecting and disconnecting terminal connectors When disassembling the wire harness, grasp its connector, not the wire harness itself. In order to separate the connectors, first release the lock
4. Precautions for using circuit tester Before using the circuit tester, please refer to the instruction of the circuit tester manual, and then adjust the circuit tester to be suitable for the object to be measured, voltage range and current electrode
